2022 Mercury 40ELHPT SeaPro 40HP Command Thrust EFI Outboard Motor

Mercury 40HP SeaPro Command Thrust Outboard Motor

The 2022 Mercury 40ELHPT SeaPro 40HP Outboard Motor is engineered for demanding commercial and professional marine environments. Built with Mercury’s SeaPro commercial-grade durability, this powerful outboard delivers exceptional reliability, fuel efficiency, and performance for heavy-duty boating applications.

Powered by a 995cc inline 4-cylinder SOHC engine, this outboard provides strong torque and smooth operation while maintaining excellent fuel economy. The integrated Electronic Fuel Injection (EFI) system ensures fast starting, consistent throttle response, and efficient fuel delivery in all operating conditions.

This model is equipped with Mercury’s Command Thrust gearcase, which features a larger gear housing and deeper propeller placement. This system provides improved propulsion, increased boat control, and better performance when pushing heavier loads or operating in rough water conditions.

The Big Tiller handle offers advanced control directly from the tiller, allowing operators to manage steering, throttle, shifting, and trim easily. This makes the engine ideal for commercial fishing boats, workboats, patrol boats, and larger aluminum boats.

The Power Trim system allows precise adjustment of the engine angle, improving fuel efficiency, acceleration, and overall handling. In addition, Mercury’s SmartCraft Engine Guardian protection system continuously monitors engine performance and alerts the operator to potential issues.

Constructed with marine-grade materials and corrosion-resistant coatings, this outboard is designed for durability in both freshwater and saltwater environments.

Manufactured by Mercury Marine, a global leader in marine propulsion technology,the SeaPro 40HP Command Thrust offers commercial-grade reliability and long-lasting performance.

Australia and New Zealand.

---

Key Features

Commercial-Grade SeaPro Durability

• Built for heavy-duty commercial applications

• Designed for extended engine life and reliability

Powerful 4-Cylinder Engine

• Inline 4-cylinder SOHC engine

• Large 995cc displacement for strong torque

• Smooth and efficient power delivery

Electronic Fuel Injection (EFI)

• Reliable and fast engine starting

• Optimized fuel economy

• Consistent throttle response

Command Thrust Gearcase

• Larger gearcase for increased propulsion

• Improved control for heavier boats

• Deeper propeller placement for better performance

Big Tiller Control System

• Advanced tiller steering system

• Integrated throttle and shift control

• Easy operation for professional boat operators

SmartCraft Engine Technology

• SmartCraft Engine Guardian protection system

• Compatible with SmartCraft digital monitoring systems

Power Trim System

• Easy trim adjustment

• Improved fuel efficiency and handling

---

Technical Specifications

Model: 40ELHPT SeaPro®
Model Year: 2022

Manufacturer: Mercury Marine

Horsepower: 40 HP

Engine Type: Inline 4-Cylinder, 8-Valve SOHC

Displacement:
995 cc (60.8 CID)

Bore × Stroke:
65 × 75 mm (2.56 × 2.95 in)

Full Throttle RPM Range:
4500 – 5500 RPM

Shaft Length:
20″ Long Shaft

Gearcase Ratio:
2.33:1 Command Thrust

Fuel System:
Electronic Fuel Injection (EFI)

Ignition System:
SmartCraft ECM 07 Digital Inductive

Starting System:
Electric Start (Turn-Key)

Steering:
Big Tiller Handle

Controls:
Mechanical throttle & shift (sold separately)

Cooling System:
Water-cooled with thermostat

Lubrication System:
Wet sump

Trim System:
Power Trim

Alternator Output:
18 Amp / 226 Watt

Exhaust System:
Through-propeller exhaust

Recommended Fuel:
Unleaded 87 Octane (maximum 10% ethanol)

Recommended Oil:
NMMA Certified FC-W SAE 25W-40

Dry Weight:
260 lbs

CARB Rating:
3-Star Ultra Low Emissions

---

Equipment

Propeller: Not included (recommended to consult dealer for proper propeller selection)
Color: Phantom Black

---

Ideal Applications

This powerful SeaPro outboard is ideal for:

• Commercial fishing boats

• Workboats and utility boats

• Patrol and service vessels

• Aluminum fishing boats

• Heavy-load recreational boats
